MSI ODBC Tables

MSI ODBC Tables ,The Open Database Connectivity (ODBC) tables group consists of five tables that allow the Installer to install ODBC drivers and data sources.

The ODBCDataSource Table:

What is a ODBCDataSource table?

The ODBCDataSource table lists the ODBC data sources in the installation. This table has following columns:

DataSource:

This is an arbitrary string identifying the data source to the Installer.

Component_:

The data source is installed as part of the referenced component.

Description:

This is the description that should be shown to the user when they browse to the data source on their machine. Its length cannot exceed cannot SQL_MAX_DSN_LENGTH.

DriverDescription:

This is the driver name to be used for this data source. This might be a driver in the ODBCDriver table, or it might be a driver that’s already on the user’s computer.

Registration:

This column can contain either 0, to register the data source per-machine, or 1, to register the data source per-user.

The ODBCDriver Table:

What is an ODBCDriver table?

The ODBCDriver table contains the information needed to install ODBC drivers. This table includes the following columns:

Driver:

This is an arbitrary key for this table.

Component_:

It indicates the component that includes this driver.

Description:

This is the non-localizable ODBC key for the driver.

File:

It must point to the DLL that contains the ODBC driver.

File_Setup:

It can be used to indicate a DLL that is called to do the setup of the listed ODBCdriver. If this column is null, then the file listed in the File_ column is assumed to handle its own setup duties.

The ODBCTranslator Table:

What is an ODBCTranslator table? ODBCTranslator table is used to install ODBC translation DLLs. This table includes the following columns:

Translator:

A primary key for the table.

Component_:

This column indicates the component that includes this translator.

Description:

This is the non-localizable description of this translator.

File_:

It must point to the DLL that contains the ODBC translator.

File_Setup:

It can be used to indicate a DLL that is called to do the setup of the listed ODBC translator. If this column is null, then the file listed in the File_ column is assumed to handle its own setup duties.

The ODBCAttribute Table:

What is an ODBCAttribute table?

This table contains attributes for ODBC drivers that need to be registered when the drivers are installed. This table includes following columns:

Driver_:

It indicates the driver that requires this attribute.

Attribute:

This column indicates the name of the attribute.

Value:

This column contains the value to be registered for the attribute.

The ODBCSourceAttribute Table:

What is an ODBCSourceAttribute table? The ODBCSourceAttribute table contains attributes for ODBC data sources that need to be registered when the data sources are installed. This table includes following columns:

DataSource:

It indicates the data source that requires this attribute.

Attribute:

This column holds the name of the attribute.

Value:

This column contains the value to be registered for the attribute.
